| Model | Design Speed(m/min) | Economic Speed(m/min) | Working Width(mm) | Multi-ply Board |
| LUM-A-100 | 100 | 60-80 | 1400-2000 | 3/5/7 ply |
| LUM-B-150 | 150 | 80-120 | 1400-2200 | 3/5/7 ply |
| LUM-C-200 | 200 | 120-150 | 1400-2200 | 3/5/7 ply |
| LUM-D-300 | 300 | 150-200 | 1400-2200 | 3/5/7 ply |
High Precision Alloy Steel Corrugated Roller
Tungsten Carbide Corrugated Roller
Main characteristics:
1.The material is high quality CrMo alloy steel or quality roller coated with tungsten.
2.Flute is UV shape which is widely used in the world, low paper shrinkage,high quality and strong paperboard.
3.Adopt imported precision machine tools,advanced molding grinding and electroplating,flute precision apply to national standard.
4.The surface of corrugated roller flute teeth are middle-frequency quenched,hardness reach HRC60,upper corrugated roller is drum shape,with long life.
